Base mat NP-R for Cofloor thin-layer system
1.0 x 1.0 m, without thermal insulation

Please wait!

Base mat NP-R for thin-layered system 1.0 x 1.0 m = 1.0 m²

Pre-punched base mat without thermal insulation made of moulded polystyrene foil with foil overlap on both sides, with adhesive layer on reverse, for fixing 12 mm pipes offering the possibility of 45 ° diagonal laying without auxiliary material, laying distances 5, 10 and 15 cm

Tested minimum construction heights: -Knauf levelling compound Alphadur 430 min. 17 cm -PCI periplan min. 18 mm -Weber-Maxit weber.floor min. 18 mm -Knauf levelling screed 425 min. 21 mm
Art.No.: 1402010
EAN: 4026755342796
Manufacturer: Oventrop GmbH & Co. KG
Subject to technical changes.
Download GAEB


Download tender text

Accessories

Edge insulating strip with self-adhesive base, height: 50 mm, thickness: 5 mm, roll length: 20 m, only suitable for base mat NP-R
Item no. 1401990
Edge insulating strip with foil for sealing to the laying system, height: 150 mm, thickness: 10 mm, roll length: 25 m
Item no. 1402090
Expansion joint profile height: 120 mm, thickness: 10 mm, length: 1.20 m
Item no. 1402091
Edge insulating strip with self-adhesive foil for sealing to the laying system, self-adhesive on the wall side, height: 150 mm, thickness: 10 mm, roll length: 25 m
Item no. 1402191
Marker point for measuring screed humidity made of plastic, set = 5 pieces
Item no. 1409090
Protective pipe made of LDPE, 300 mm, slotted
Item no. 1501184

Dimensions

Dimensions of article

Length Width Height Weight
1030 mm 1030 mm 14 mm 0,94 kg

Packing units

Type Qty. Length Width Height Weight
Carton 1 1030 mm 1030 mm 14 mm 0,94 kg
Unknown 10 1070 mm 1065 mm 170 mm 12,6 kg
Europallet 50 1200 mm 800 mm 1225 mm 85 kg

Images

Product images

  File size
634,73 KB
  Size
2048 px x 2048 px
  Properties
  •  Clear product picture
  •  Cutout
Download
  File size
771,71 KB
  Size
2384 px x 2048 px
  Properties
  •  Clear product picture
  •  Cutout
Download
  File size
295,64 KB
  Size
945 px x 709 px
  Properties
  •  Clear product picture
  •  Cutout
Download

Drawings

  File size
24,07 KB
  Size
298 px x 224 px
  Properties
  •  Clear product picture
  •  Cutout
Download

ETIM

Klassifizierung
ETIM 7.0 EC011767
Insulation board, floor heating
Property Value
Width 1000 mm
Length 1 mm
Material Polystyrene
Suitable for pipe diameter 12 mm
Studded panel
Tacker plate
Inlay plate
With foil
Thickness including studs Other
