Toc-Uno Heating oil deaerator
DN 10, tank side G ¼ IT, burner side G ⅜ ET (brass), with hose

Toc-Uno heating oil deaerator

For automatic venting of oil firing systems that are operated as one pipe systems with return flow feed (suction operation). Deaeartor body made of metal for wall mounting. Dearator cap made of transparent plastic for function control of the safety float.

Max. nozzle capacity: 110 l/h EL heating oil
Max. flow of returned oil: 120 l/h EL heating oil
Min. venting capacity: 6 l/h air

Connection tank side: G ¼ internal thread
Connection burner side: G ⅜ external thread (brass)

With hose G ⅜ union nut x G ¼ external thread, length 300 mm
Art.No.: 2142900
EAN: 4026755309874
Manufacturer: Oventrop GmbH & Co. KG
Subject to technical changes.


Dimensions of article

Length Width Height Weight
110 mm 100 mm 140 mm 0,74 kg

Packing units

Type Qty. Length Width Height Weight
Carton 1 110 mm 100 mm 140 mm 0,79 kg
Unknown 528 1200 mm 800 mm 950 mm 497,65 kg
